Airwell DAF009 - 5.5 YIF030 Performance Data

PERFORMANCE DATA & PRESSURE CURVES
5-10 SM YIF 2-A.1 GB
Suction Pressure VS.Outdoor Temp
5.0
7.0
9.0
11.0
15 20 25 30 35 40 46
Outdoor Temp.(
o
C DB
)
Suction Pressure(Bar)
15/21(WB/DB)
17/24(WB/DB)
19/27(WB/DB)
21/29(WB/DB)
23/32(WB/DB)
Heating
Discharge Pressure VS.Outdoor Temp
10.0
20.0
30.0
40.0
-10-7 -2 2 6 101520
Outdoor Temp.(
o
C WB)
Discharge Pressure(Bar)
25 C DB
20 C DB
15 C DB
5.5 YIF030
5.5.1 Cooling Capacity (kW)
