PERFORMANCE DATA & PRESSURE CURVES
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.6.2 Heating Capacity (kW)
ENTERING AIR DB ID COIL(
O
c)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 5.78 2.80 5.56 2.98 5.34 3.13
-7 6.22 2.87 6.00 3.03 5.78 3.19
-2 6.60 2.91 6.38 3.08 6.16 3.26
2 8.03 3.05 7.70 3.24 7.37 3.43
6 11.33 3.27
11.00 3.50
10.62 3.72
10 12.32 3.45 11.99 3.69 11.66 3.95
15 13.31 3.61 12.98 3.89 12.65 4.13
20 14.03 3.71 13.70 4.03 13.31 4.34
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.6.3 Curves
Cooling
5-14 SM YIF 2-A.1 GB
