INTRODUCTION
1-2 SM YIF 2-A.1 GB
1.3 Indoor Unit
The indoor unit is calling mounted, and can be easily fitted to many types of residential
and commercials applications. It is major designed for light commercial air-conditioning
needs.
It includes:
• Coil with hydrophilic aluminum fins.
• Advanced electronic control box assembly
• Mounting plate
1.4 Filtration
The YIF series presents several types of air filters:
• Easily accessible, and re-usable pre-filters (mesh)
1.5 Control
The microprocessor indoor controller, and an infrared remote control, supplied as
standard, provide complete operating function and programming. For further details,
please refer to the Operation Manual, Appendix.
1.6 Outdoor Unit
The outdoor units can be installed as floor or wall mounted units by using a wall
supporting bracket. The metal sheets are protected by anti- corrosion paint work
allowing long life resistance. For further information, please refer to the Product Data
Sheet, Chapter 2.
It includes :
• Compressor mounted in a soundproofed compartment :
• Axial fan.
• Outdoor coil with hydrophilic louver fins for RC units.
• Outlet air fan grill.
• Interconnecting wiring terminal block.
1.7 Tubing Connections
Flare type interconnecting tubing to be produced on site.
For further details, please refer to the Installation Manual, Chapter 10.
