PERFORMANCE DATA & PRESSURE CURVES
SM FLODCI 2-A.4 GB
5.7.6 Heating — Test Mode
Suction Pressure VS. Outdoor Temp.
300
400
500
600
700
800
900
1000
1100
1200
-15 -10 -5 0 5 10 15
Outdoor WB Temperature[
o
C]
Suction Pressure [kPa]
15
20
25
Discharge Pressure VS. Outdoor Temp.
1500
2000
2500
3000
3500
4000
-15 -10 -5 0 5 10 15
Outdoor WB Temperature[
o
C]
Discharge Pressure [kPa]
15
20
25
Indoor DB
Indoor DB
