PERFORMANCE DATA & PRESSURE CURVES
SM FLODCI 2-A.4 GB
5.7.8 Heating — Test Mode
Suction Pressure vs. Outdoor Temperature
300
400
500
600
700
800
900
1000
1100
1200
-15 -10 -5 0 5 10 15
Outdoor WB Temperature
Suction Pressure [kPa]
15
20
25
Discharge Pressure vs. Outdoor Temperature
1500
1750
2000
2250
2500
2750
3000
3250
3500
3750
4000
-15 -10 -5 0 5 10 15
Outdoor WB Temperature
Discharge Pressure [kPa]
15
20
25
Indoor DB
Indoor DB
