Page 41
Technical data
English
CLC ELN 182 202 242 302 352
Power supply
V/ph/Hz
400/3/50
Number of circuit 22222
Number of steps 22223
Capacity control steps %
50/100 50/100 50/100 50/100 43-57/100
Compressors
Type Scroll Scroll Scroll Scroll Scroll
Number 22222
Start-up type Direct
Condenser
Type Coil type (Al/Cu)
Refrigerant connections
Type To be welded
Liquid diameter inch 1/2” 1/2” 5/8” 5/8” 5/8”
Suction diameter inch 7/8” 7/8” 1
5
/8”1
5
/8”1
5
/8
Weights
Shipping weight kg 620 641 772 786 903
Dimensions
Length mm 2100 2100 2100 2100 2760
Width mm 1110 1110 1110 1110 1110
Height mm 1850 1850 1850 1850 1850
(1) Indicative value. Always refer to the value specified on the unit’s label.
CLC ELN 402 502 552 602
Power supply
V/ph/Hz
400/3/50
Number of circuit 2222
Number of steps 2232
Capacity control steps %
50/100 50/100 43-57/100 50/100
Compressors
Type Scroll Scroll Scroll Scroll
Number 2222
Start-up type Direct
Condenser
Type Coil type (Al/Cu)
Refrigerant connections
Type To be welded
Liquid diameter inch 5/8” 5/8” 5/8” 5/8”
Suction diameter inch 1
5
/8”1
5
/8”1
5
/8”1
5
/8
Weights
Shipping weight kg 919 1015 1151 1187
Dimensions
Length mm 2760 3110 3110 3110
Width mm 1110 1110 1110 1110
Height mm 1850 1850 1850 1850
(1) Indicative value. Always refer to the value specified on the unit’s label.
Manuale CLS-CLH1 7.2.2005 10:17 Pagina 41
