Technical data
8.3 Unit Electrical data
CLS/CLC STD 182 202 242 302 352
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 18.8 25.4 30.0 35.6 42.5
Rated current A 22.2 30.6 41.9 50.5 58.5
Max. current (FLA) A 32.1 43.3 49.9 59.9 70.3
Max. start-up current (LRA) A 116.0 149.6 175.9 205.9 246.8
External fuses (A) 50 63 63 80 100
Max. cable section (1) mm
2
16 25 25 35 35
CLS STD with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 19.6 26.2 31.5 37.1 44.3
Rated current A 24.3 32.7 45.7 54.3 63.4
Max. current (FLA) A 34.2 45.4 53.7 63.7 75.2
Max. start-up current (LRA) A 118.1 151.6 179.7 209.7 251.7
External fuses (A) 50 63 63 80 100
Max. cable section (2) mm
2
16 25 25 35 35
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
(2) Data which refer to a single pump.
CLS/CLC STD 402 502 552 602
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 49.0 59.4 64.7 71.8
Rated current A 65.6 79.8 81.3 91.2
Max. current (FLA) A 79.8 97.2 108.8 119.8
Max. start-up current (LRA) A 256.3 320.0 370.0 381.0
External fuses (A) 100 125 125 160
Max. cable section (1) mm
2
35 50 70 70
CLS STD with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 50.8 61.2 66.5 73.6
Rated current A 70.5 84.7 86.2 96.1
Max. current (FLA) A 84.7 102.1 113.7 124.7
Max. start-up current (LRA) A 261.2 324.9 375.0 386.0
External fuses (A) 100 125 125 160
Max. cable section (2) mm
2
35 50 70 70
