Technical data
CLS/CLC LN-ELN 182 202 242 302 352
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 19.3 25.9 30.4 36.0 43.2
Rated current A 22.6 31.0 42.3 50.9 59.2
Max. current (FLA) A 32.5 43.7 50.3 60.3 71.0
Max. start-up current (LRA) A 116.4 150.0 176.3 206.3 247.5
External fuses (A) 50 63 63 80 100
Max. cable section (1) mm
2
16 25 25 35 35
CLS LN-ELN with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 20.1 26.7 31.9 37.5 45.0
Rated current A 24.7 33.1 46.1 54.7 64.1
Max. current (FLA) A 34.6 45.8 54.1 64.1 75.9
Max. start-up current (LRA) A 118.5 152.1 180.1 210.1 252.4
External fuses (A) 50 63 63 80 100
Max. cable section (2) mm
2
16 25 25 35 35
Unit Electrical data
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
(2) Data which refer to a single pump.
CLS/CLC LN-ELN 402 502 552 602
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 49.7 60.1 65.4 72.5
Rated current A 66.3 80.5 82.0 91.9
Max. current (FLA) A 80.5 97.9 109.5 120.5
Max. start-up current (LRA) A 257.0 320.7 371.0 382.0
External fuses (A) 100 125 125 160
Max. cable section (1) mm
2
35 50 70 70
CLS LN-ELN with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 51.5 61.9 67.9 74.3
Rated current A 71.2 85.4 86.9 96.8
Max. current (FLA) A 85.4 102.8 114.4 125.4
Max. start-up current (LRA) A 261.9 325.6 376.0 387.0
External fuses (A) 100 125 125 160
Max. cable section (2) mm
2
35 50 70 70
