Airwell Itelco-Clima CLS 182 STD - 8.3 Unit Electrical Data: Compressors and Pumps

Page 52
CLS/CLC HT-HPF 402 502 552 602
Rated voltage
V(%)/ph/Hz 400 ±10% / 3 / 50
Max. absorbed power kW 50.5 60.9 64.7 73.3
Rated current A 67.9 82.1 83.6 93.5
Max. current (FLA) A 82.1 99.5 111.1 122.1
Max. start-up current (LRA) A 258.6 322.3 373.0 384.0
External fuses (A) 100 125 125 160
Max. cable section (1) mm
2
35 50 70 70
CLS HT-HPF with pump
Rated voltage
V(%)/ph/Hz 400 ±10% / 3 / 50
Max. absorbed power kW 52.3 62.7 66.5 75.1
Rated current A 72.8 87.0 88.5 98.4
Max. current (FLA) A 87.0 104.4 116.0 147.0
Max. start-up current (LRA) A 263.5 327.2 378.0 389.0
External fuses (A) 100 125 125 160
Max. cable section (2) mm
2
35 50 70 70
Technical data
CLS/CLC HT-HPF 182 202 242 302 352
Rated voltage
V(%)/ph/Hz 400 ±10% / 3 / 50
Max. absorbed power kW 19.8 26.4 31.0 36.6 44.0
Rated current A 23.7 32.1 43.4 52.0 60.8
Max. current (FLA) A 33.6 44.8 51.4 61.4 72.6
Max. start-up current (LRA) A 117.5 151.1 177.4 207.4 248.0
External fuses (A) 50 63 63 80 100
Max. cable section (1) mm
2
16 25 25 35 35
CLS HT-HPF with pump
Rated voltage
V(%)/ph/Hz 400 ±10% / 3 / 50
Max. absorbed power kW 20.6 27.2 32.5 38.1 45.8
Rated current A 25.8 34.2 47.2 55.8 65.7
Max. current (FLA) A 35.7 46.9 55.2 65.2 77.5
Max. start-up current (LRA) A 119.6 153.2 181.2 211.2 254.0
External fuses (A) 50 63 63 80 100
Max. cable section (2) mm
2
16 25 25 35 35
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
(2) Data which refer to a single pump.
Unit Electrical data
