Page 58
CLH HPF 402 502 552 602
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 51.4 59.1 66.2 73.3
Rated current A 58.5 73.8 83.6 93.5
Max. current (FLA) A 87.1 100.1 111.1 122.1
Max. start-up current (LRA) A 271 325 373 384
External fuses (A) 100 125 125 160
Max. cable section (1) mm
2
35 50 70 70
CLH HPF with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 53.2 60.9 68.0 75.1
Rated current A 63.4 78.7 88.5 98.4
Max. current (FLA) A 92.0 105.0 116.0 127.0
Max. start-up current (LRA) A 276 330 378 389
External fuses (A) 100 125 125 160
Max. cable section (2) mm
2
35 50 70 70
Technical data
CLH HPF 182 202 242 302 352
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 19.8 26.4 32.0 37.5 43.6
Rated current A 23.7 32.1 43.4 53.7 53.6
Max. current (FLA) A 33.6 44.8 51.4 63.1 73.9
Max. start-up current (LRA) A 118 151 177 209 258
External fuses (A) 50 63 63 80 100
Max. cable section (1) mm
2
16 25 25 35 35
CLH HPF with pump
Rated voltage
V(%)/ph/Hz
400 ±10% / 3 / 50
Max. absorbed power kW 20.6 27.2 33.5 39.0 45.4
Rated current A 25.8 34.2 47.2 57.5 58.5
Max. current (FLA) A 35.7 46.9 55.2 66.9 78.8
Max. start-up current (LRA) A 120 153 181 213 263
External fuses (A) 50 63 63 80 100
Max. cable section (2) mm
2
16 25 25 35 35
(1) The dimensioning of the unit’s power cables is the responsibility of the installer, who shall consider: the rating, the maximum working temperature
in the room, the type of insulation and the cable laying, the maximum length of the power supply line.
(2) Data which refer to a single pump.
Unit Electrical data
