Page 59
English
Technical data
Compressorsi CLH 182 202 242 302 352
Number 22222
Absorbed power rating, compr. 1 kW 6 8.5 12 13.7 12.9
Absorbed power rating, compr. 2 kW 6 8.5 12 13.7 15.8
Max. absorbed power, compr. 1 kW 9 12 15 17 16
Max. absorbed power, compr. 2 kW 9 12 15 17 24
Rated current, compressor 1 A 10.1 14.4 20 24.3 21.8
Rated current, compressor 2 A 10.1 14.4 20 24.3 26.7
Max. current (FLA), compressor 1 A 15 21 24 29 28
Max. current (FLA), compressor 2 A 15 21 24 29 41
Max. start-up current (LRA) compr. 1 A 99 127 150 175 198
Max. start-up current (LRA) compr. 2 A 99 127 150 175 225
Oil pan resistor, compressor 1 W 70 70 65 75 70
Oil pan resistor, compressor 2 W 70 70 65 75 120
Pump (unit with 1 pump)
Supply voltage V-ph-Hz 400 / 3 / 50
Rated power kW 0.8 0.8 1.1 1.1 1.5
Absorbed rated current A 1.7 1.7 3.1 3.1 3.8
Pump (unit with 2 pumps)
Supply voltage V-ph-Hz 400 / 3 / 50
Rated power (2) kW 0.8 0.8 1.5 1.5 1.8
Absorbed rated current (2) A 2.1 2.1 3.8 3.8 4.9
Compressors CLH 402 502 552 602
Number 2222
Absorbed power rating, compr. 1 kW 15.8 18.8 20.3 25.3
Absorbed power rating, compr. 2 kW 15.8 18.8 25.3 25.3
Max. absorbed power, compr. 1 kW 24 28 28 35
Max. absorbed power, compr. 2 kW 24 28 35 35
Rated current, compressor 1 A 26.7 31.8 34.3 44.2
Rated current, compressor 2 A 26.7 31.8 44.2 44.2
Max. current (FLA), compressor 1 A 41 48 48 59
Max. current (FLA), compressor 2 A 41 48 58.5 59
Max. start-up current (LRA) compr. 1 A 225 272 272 320
Max. start-up current (LRA) compr. 2 A 225 272 320 320
Oil pan resistor, compressor 1 W 120 150 150 150
Oil pan resistor, compressor 2 W 120 150 150 150
Pump (unit with 1 pump)
Supply voltage V-ph-Hz 400 / 3 / 50
Rated power kW 1.8 1.8 1.8 1.8
Absorbed rated current A 4.9 4.9 4.9 4.9
Pump (unit with 2 pumps)
Supply voltage V-ph-Hz 400 / 3 / 50
Rated power (2) kW 1.8 1.8 1.8 1.8
Absorbed rated current (2) A 4.9 4.9 4.9 4.9
2) Data which refer to a single pump.
Electrical Data Compressors and pumps
