Technical data
A
C
B
177
177
Lifting point
cable inlet
Lifting point
VIEW A
36.5 36.5
1037
1110
A
C
35 mm
for transport
only
VIEW B
1100
B
(+35 mm for transport only)
~368
~470 ~404
2" male
with tank
VIEW C
CLS 352-602 STD-LN-ELN-HT-HPF
Note: Do not extract dimensions if not specifyed in the drawings.
Models Versions Dimensions A (mm) Dimensions B (mm) Dimensions C (mm)
STD 2406 2760 1750
LN/ELN/HT/HPF 2406 2760 1850
STD 2756 3110 1750
LN/ELN/HT/HPF 2756 3110 1850
CLS 352-
402
CLS 502-
552-602
2"
VIEW C
without tank
501
784 470
2” male
