TROUBLESHOOTING
Version - 1 52 DCH DCI
2. Compressor checking
Measure the resistance value of each winding by using the tester.
Position
Resistance Value
ASK89D53UEZ
ASM135D23UFZ
ATF235D22UMT
Blue - Red
2.35Ω
(20℃/68℉)
1.75Ω
(20℃/68℉)
0.75Ω
(20℃/68℉)
Blue - Black
Red - Blue
