SPECIFICATION
DCH DCI 7 Version - 1
3. Specification
3.1 Model: JOSI-DCH009-N11 / JOAU-DCY009-H11
MODEL INDOOR UNIT
JOSI-DCH009-N11
Model Outdoor Unit
AWAU-YCD009-H11
Installation Method of Pipe
Flared
Characteristics
Units
Cooling
Heating
Average
Warm
Cold
Capacity
(1)
kW
2.65 (1.0 -3.2)
2.7(0.82-3.3)
Pdesign
kW
2.65
2.2
2.8
-
SEER /SCOP
(2)
W/W
6.1
4
5.1
-
Energy efficiency class
A++
A+
A+++
-
Annual energy consumption
kWh
153
770
769
-
Tbiv
o
C
N/A
-7
2
-
Tol
o
C
N/A
-15
Power supply
V/Ph/Hz
220-240V/Single/50Hz
Circuit breaker rating
A
10
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
VL/L/M/H
RPM
800 /1000 /1150
Air flow
(3)
VL/L/M/H
m3/hr
270/320/420
External static pressure
Min-Max
Pa
0
Sound power level
(4)
VL/L/M/H
dB(A)
54
Sound pressure level
(5)
VL/L/M/H
dB(A)
23/29/34/38
Moisture removal
l/hr
1
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
715x285x194
Weight
kg
6.8
Package dimensions
WxHxD
mm
780x360x270
Packaged weight
kg
8.9
Stacking height
units
7
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter
Fan type & quantity
Axial x 1
Fan speeds
H
RPM
810
Air flow
H
m3/hr
1800
Sound power level
(4)
H
dB(A)
61
Sound pressure level
(5)
H
dB(A)
51
Dimensions
WxHxD
mm
770x555x300
Weight
kg
25.2
Package dimensions
WxHxD
mm
900x585x345
Packaged weight
kg
27.4
Stacking height
Units
4
Refrigerant type
R410A
Refrigerant charge (standard connecting tubing length)
kg(5m)
0.8
Additional charge per 1 meter
gr / 1m
15
Connections between
units
Liquid line
In.(mm)
1/4’’
Suction line
In.(mm)
3/8’’
Max.tubing length
m.
25
Max.height difference
m.
10
Operation control type
Remote control
Heating elements
kW
NA
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2) SEER / SCOP calculation accordance with EN14825.

Airwell johnson DCH Series Specifications

General

Brand	Airwell
Model	johnson DCH Series
Category	Air Conditioner
Language	English
