Airwell johnson DCH Series User Manual

EXPLODED VIEW AND SPARE PART LIST
Version - 1 56 DCH DCI
11.4 Spare part list of model: JOSI-DCH018-N11
No.
BOM Code
Part Name
Quantity
1
12122000A49214
Panel assembly
1
2
12100204001559
Air filter
2
3
17222000A45948
Display box assembly
1
3.1
17122000A22268
Display board assembly
1
4
12122000013131
Cover of electrical equipment
1
5
12122000013179
Panel frame assembly
1
5.1
12122000013139
Screw cap
2
6
12122000013175
Right cover of chassis
1
7
12122000013141
Terminal cover assembly
1
8
12122000013187
Horizontal louver assembly
1
9
15822000004976
Evaporator assembly Gas valve assembly
1
10
12122000013176
Fan motor cover
1
11
11002015000139
Brushless DC Motor
1
12
12122000000350
beating base jacket
1
13
12622000000006
Beating base
1
14
12100102000131
Cross-flow Window Rotor.
1
16
12122000013181
Chassis assembly
1
16.1
11002010000143
stepper motor
1
16.3
12122000013183
Vertical vane
1
16.4
12122000013186
Left cover of chassis
1
17
12122000013178
Pipe clamp board
1
18
12222000005866
Installation plate
1
19
17222000A45329
Electronic control box assembly
1
19.4
17122000024357
Indoor Main Control Board Subassembly (Sticker)
1
19.5
12122000013001
Electronic installing box
1
19.6
11201007000322
Temperature Sensor
1
19.7
17400401000576
Wire joint
1
19.9
11201007000088
Room Temperature Sensor
1
20
12122000013132
Cover of electronic control box
1
21
17317000A02580
Remote controller
1
22
12600701000039
Seal ring
1
23
12100509000061
Drain hose
1
29
12100501000032
Drain Hose
1
40
12100204000685
Air freshening filter
1
40
12100207000007
Air freshening filter
1
42
15500209000001
Detection valve
1
45
12117000000086
Mounting bracket of remote controller
1
46
15500404000009
plastic nut
1
46
15500406000012
Copper nut
1
46
15500406000016
Copper nut
1
