EXPLODED VIEW AND SPARE PART LIST
Version - 1 58 DCH DCI
11.6 Spare part list of model: JOSI-DCH024-N11
No.
BOM Code
Part Name
Quantity
1
12122000A49215
Panel assembly
1
2
12122000015222
Air filter
2
3
17222000A45948
Display box assembly
1
3.1
17122000A22268
Display board assembly
1
4
12122000013357
Cover of electrical equipment
1
5
12122000013353
Panel frame assembly
1
5.1
12122000013355
Screw cap
2
7
12122000013350
Terminal cover assembly
1
8
12122000013348
Horizontal louver assembly
1
9
15822000004857
Evaporator assembly Gas valve assembly
1
10
12122000013349
Fan motor cover
1
11
11002015000094
Brushless DC Motor
1
12
12122000000350
beating base jacket
1
13
12622000000006
Beating base
1
14
12100102000002
Cross fan ass'y
1
16
12122000013341
Chassis Assembly
1
16.1
11002010000049
stepper motor
1
16.3
12122000013343
Vertical vane
3
16.4
12122000013342
Left cover of chassis
1
17
12122000013346
Pipe clamp board
1
18
12222000005965
Installation plate
1
19
17222000A45332
Electronic control box assembly
1
19.4
17122000024354
Indoor Main Control Board Subassembly (Sticker)
1
19.5
12122000013004
Electronic installing box
1
19.6
11201007000322
Temperature Sensor
1
19.7
17400401000576
Wire joint
1
19.9
11201007000088
Room Temperature Sensor
1
20
12122000013356
Cover of electronic control box
1
21
17317000A02580
Remote controller
1
22
12600701000039
Seal ring
1
23
12100509000061
Drain hose
1
29
12100501000032
Drain Hose
1
40
12100204000685
Air freshening filter
1
40
12100207000007
Air freshening filter
1
42
15500209000002
detection valve
1
45
12117000000086
Mounting bracket of remote controller
1
46
15500404000005
Pipe Nut
1
46
15500406000003
Copper net
1
46
15500406000010
Copper nut
1
