ICE CFA1120A-3360A & CGA3180A I&O Manual 03/2021 Rev.5
1.2 Model Identication
The model identication number is found on the data sticker. Rating plate located on side panel.
Example C F A 3 1 8 0 A D 0 5 0 D R + + + 1 C A + A 2 1 + + + + +
+
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
1 Unit Designation/Family C = Industrial Climate Engineering (ICE)
2 Energy Efciency Ratio (EER)
F = EER <9
G = 10 EER
3 Refrigerant Type A = R-410a
4 Compressor Type/Quantity
1 = Single
3 = Dual
5
Unit Capacity/Nominal
Cooling (BTUH)
120 = 120,000 240 = 240,000
150 = 150,000 300 = 300,000
180 = 180,000 360 = 360,000
6
7
8 System Type A = Air Conditioner
9
Power Supply
(Volts-Phase-Hz)
A = 208/230-1-60 E = 380-3-50 (4 Wire)
C = 208/230-3-60 M = 400-3-60
D = 460-3-60 Z = 575-3-60
10
Heat Designation
@ Rated Voltage
KW = Kilowatt
000 = No Heat 150 = 15KW
050 = 5KW 180 = 18KW
090 = 9KW
11
12
13
Ventilation
Conguration
A = Solid Front Door
C = Economizer
D = Motorized Damper w/Pressure Relief
E = Motorized Damper w/Pressure
Relief & Independent Motorized
Damper Control
F = No Free Cooling, 100% Emergency
Ventilation Only w/Independent Control
14 Dehumidication
R = Electric Reheat
T = Electric Reheat w/Humidity Control
+ = None
15 Controls
A = Power Fail Alarm w/Additional Lockouts
C = 24V EMS Relay Kit
D = 24V EMS Relay Kit
w/Factory Installed T-Stat
E = Factory Installed T-Stat
+ = None
16 Operating Condition
A = Evaporator Freeze Sensor (EFS)
C = EFS w/Hot Gas Bypass
M = Extreme Duty w/Hard Start & EFS
N = Hard Start
P = Hard Start w/Low Ambient & CCH
Q = Hard Start w/Low Ambient &
Fan Cycle Control (FCC)
R = Crank Case Heater (CCH)
T = Hard Start w/EFS
U = Hard Start w/Hot Gas Bypass
V = Hard Start w/Low Ambient &
CCH & EFS
W = Low Ambient w/CCH
X = Hot Gas Bypass
Y = Low Ambient w/CCH & FCC
Z = Low Ambient w/CCH & EFS
1 = Low Ambient w/FCC
2 = Low Ambient w/FCC & EFS
3 = CCH w/Hot Gas Bypass
+ = None
Note: Not all options are available with all congurations.
Contact your ICE sales representative for conguration
details and feature compatibility.
17
Indoor Air Quality
Features
A = UV Light
D = Dry Bulb Sensor
E = Dry Bulb Sensor w/Dirty Filter
G = Dirty Filter Sensor
K = Bi-Polar Ionization
+ = None
18 Air Flow 1 = Top Supply/Bottom Return
19
Compressor
Location
C = Center
20 Filter Option
A = 2” Pleated (MERV 8, AC/HP-C)
C = 2” Charcoal
D = MERV 11 High Filtration Package
E = MERV 13 High Filtration Package
F = Filter Access Through Return Air Opening
G = F + C
H = F + D
J = F + E
K = F + W
W = Aluminum Washable
+ = None
21
Corrosion
Protection
A = Condenser Coil Only
C = Evaporator Coil Only
D = Both Coils Condenser & Evaporator
E = All Coils Cond/Evap/Reheat
F = Coat All
K = Coastal Package
+ = None
$ = Special
22
Engineering
Revision Level
A1
A2
23
24 Cabinet Color
1 = Beige
2 = Gray
3 = Carlsbad Canyon
4 = White
5 = Stainless Steel Exterior
6 = Dark Bronze
7 = .050 Aluminum Stucco
8 = Mesa Tan
9 = Pebble Gray
A = Stainless Steel - Unit
$ = Custom Color (Powder Coat)
25 Sound Attenuation
2 = Compressor Blanket
+ = None
26 Security Option
A = Lockable Access Plate/Tamper Proof
B = Lockable Latch/Hinge
+ = None
27
Fastener/Drain Pan
Option
A = Stainless Steel Fasteners
C = Stainless Steel Drain Pan
D = Stainless Steel Fasteners & Drain Pan
+ = None
28 Special Variation
+ = None
$ = Special Conguration Not Covered by
Model Nomenclature
29 Unused
+ = None
$ = Special
30 Unused
+ = None
$ = Special
1.3 Serial Number Date Code
20 = 2020 01 = January 05 = May 09 = September
21 = 2021 02 = February 06 = June 10= October
22 = 2022 03= March 07 = July 11 = November
23 = 2023 04 = April 08 = August 12 = December
1.4 Weights and Filter Sizes
Electrical and performance specications and dimensional drawings are in the Product Data Sheet.
Note: Follow local codes and standards when designing duct runs to deliver the required airow.
Minimize noise and excessive pressure drops caused by duct aspect ratio changes, bends, dampers and
outlet grilles in duct runs.
