ADDITIONAL EASYZONE INFORMATION
Bypass damper assembly
Fix the bypass damper to the plenum
using a sheet metal screw (Ø: 3.9 mm).
With a sharp blow, remove the pre-cut area
on the sides corresponding to the bypass.
Using a utility knife, remove the insulation
covering the bypass area and uncover the
bypass fixing slots.
Fit the bypass damper into the slots and
turn from left to right until it reaches the
stop.
Damper override
Ensure that the damper to
be overridden is closed.
Disconnect the actuator. Insert the sealing cap on
the damper.
