7
A-MIP 200 V1.06
Installation
Setting up the defibrillator
Pull on the defibrillator holding tensioner and slide the
defibrillator to the bottom of the Aivia.
The tensioner allows the defibrillator to be easily
removed in an emergency while ensuring that it is held
properly.
• Tighten the wire correctly, taking care not to break it.
Make sure that the wire cannot be removed from the slot
without being broken.
• Crimp the seal body with pliers and snip off the excess
wire.
You must install seals on both sides of the Aivia.
• Regularly inspect seal condition
• If the Aivia seals have been opened, make sure that
all items of the defibrillator are present and working
properly.
In case of any doubt, contact your defibrillator distributor.
Pictograms
The signs on the door of AIVIA inform you of what to do
in an emergency.
You must mark the emergency number to call in the
SOS pictogram if one is not already noted there.
• Ensure that these instructions remain legible and in
plain view.
2
1
1
2
Defibrillator slides in vertically.
Holding tensioner.
Installing seals
• The Aivia is shipped with two seal kits
• Seals give evidence of door opening
• Regularly inspect seal condition
Seal installation
• Completely close the Aivia door Be sure to pull the
door foot toward you before to swing the door
Slide the full length of the seal wire through the Aivia
frame hole.
• Fold the wire over the door slot
• Thread the wire through the seal body.
To Next Page
