16 ENGLISH
Additional information
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION
With 8-ohm loads, both channels driven from 150 -
6,300 Hz; rated 1.5 W per channel-minimum RMS
power, with no more than 10% total harmonic distortion
in AC operation.
OTHER SPECIFICATIONS
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: λ = 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 -20,000 Hz +1/-2dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM: 87.5 - 108 MHz
AM: 530 - 1,710 kHz
Antenna
FM: Telescopic antenna
AM: Built-in ferrite bar antenna
Cassette recorder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 120 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 80 - 10,000 Hz
General
Speaker
Full range: 10 cm dia.,
4 ohm, cone type (2)
Power output
2.0 W + 2.0 W
(at 4 ohm, 10% harmonic distortion)
Power requirements
For CD stereo radio cassette recorder:
120 V AC, 60 Hz
9 V DC, 6 size D (R20) batteries
For remote control:
3 V DC, 2 size AA (R6) batteries
Power consumption
AC 10 W
Battery life
For CD stereo radio cassette recorder
FM recording
Sony R20P: approx. 13.5 h
Sony alkaline LR20: approx. 24 h
Tape playback
Sony R20P: approx. 7.5 h
Sony alkaline LR20: approx. 15 h
CD playback
Sony R20P: approx. 2.5 h
Sony alkaline LR20: approx. 7 h
Dimensions
Approx. 390 × 170 × 259.5 mm (w/h/d)
(15
3
/
8
× 6
3
/
4
× 10
1
/
4
inches) (incl. projecting parts)
Mass
Approx. 4 kg (8 lb. 13 oz) (incl. batteries)
Supplied accessories
AC power code (1)
Remote control (1)
Design and specifications are subject to change without
notice.
COPYRIGHT
Please check the copyright lows relating to recordings
from disc or radio for the country in which the machine
is being used.
