Appendix A – Specifications
HA5-Plus Tech Specs
Video Formats
• (HD) 1920 x 1080p
• (HD) 1920 x 1080i
• (HD) 1280 x 720p
• (SD) 720 x 576p
• (SD) 720 x 576i
• (SD) 720 x 480p
• (SD) 720 x 480i
Note: HDCP content not supported
Video Input Digital
• 1x HDMI Type A connector, HDMI v1.4
• YCbCr 4:2:2/4:4:4/4:2:0
• 8 or 10-bit (HFR 4:2:2 limited to 10-bit)
• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• (HD) 1920 x 1080i 50, 59.94, 60
• (HD) 1280 x 720p 50, 59.94, 60
• (SD) 720 x 576p 50
• (SD) 720 x 576i 25
• (SD) 720 x 480p 59.94
• (SD) 720 x 480i 29.97
Video Output Digital
• 1x 3 Gb SDI (Level A or B-Dual Link)
• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• (HD) 1920 x 1080i 50, 59.94, 60
• (HD) 1280 x 720p 50, 59.94, 60
• 1x 1.5 Gb SDI
• (HD) 1920 x 1080p 23.98, 24, 25, 29.97, 30
• (HD) 1920 x 1080i 50, 59.94, 60
• (HD) 1280 x 720p 50, 59.94, 60
• 1x 270 Mb SDI
• (SD) 625i 50
• (SD) 525i 59.94
Audio Input Digital
• HDMI embedded audio, 24-bit, 8-Channel
• 2-Channel RCA style analog audio (-10 dBu nominal)
Audio Output Digital
• SDI embedded audio, 24-bit, 8-Channel
Size (w x d x h)
• 4.6” × 2.4” × 1.0”(116.84 × 60.96 × 25.4 mm)
