HA5-Plus Mini-Converter v1.8 6 www.aja.com
User Controls
Mini-Config Control
Auto controls configures the unit automatically to match the input and output
video parameters. Advanced Mini-Config control supports setting the RGB video
range, and adjusting audio input, conversion, and routing to embedded HDMI
audio.
Configuration set via Mini-Config is stored in the HA5-Plus unit through
subsequent power cycles.
Installation
Typically, HA5-Plus installation consists of the following steps:
1. Ensure the converter is disconnected from power.
2. Connect equipment to the converter HDMI input connector, the output
BNC connector, and the analog audio inputs (if used).
3. Connect audio equipment to RCA connectors (optional)
4. Apply power to the converter (AJA power supply included).
5. The converter will now run using the default factory settings. If you wish to
alter the factory settings, you’ll need to:
• Install the AJA Mini-Config software on your computer
• Attach the converter via USB
• Make your changes using Mini-Config setup screens.
• This process is detailed in "Chapter 2 Operation" on page 7.
