AJAX Button User Manual

Mute Fire Alarm
By pressing the Button, the fire signal can be muted (if the corresponding operating
mode is selected). The reaction of the system to pressing a button depends on the
settings and the state of the system:
Placement
Button can be fixed on a surface or carried around.
How to fix Button
To fix Button on a surface (e. g. under a table), use Holder.
To install the button in the holder:
setting is not available. During the scenario execution, this relay will close/open the
contacts for a set time. The operating mode and pulse duration are set in the
.
Relay
settings
9. Click Save. The scenario will appear in the list of device scenarios.
Interconnected FireProtect Alarms are disabled — pressing the Button mutes
the sirens of triggered FireProtect/FireProtect Plus detectors.
The Interconnected FireProtect Alarms have already propagated — by the first
press of the Button, all fire detectors sirens are muted, except for those that
registered the alarm. Pressing the button again mutes the remaining detectors.
The interconnected alarms delay time lasts — the siren of the triggered
FireProtect/FireProtect Plus detector is muted by pressing.
Learn more about interconnected alarms of fire detectors
1. Choose a location to install the holder.

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
