AJAX Button User Manual

corresponding command to the
hub
Feedback Indication
(follows the Command Delivery
Indication)

Lights up green for about half a
second after the command
delivery indication
The security system has
received and performed the
command
Briefly lights up red after the
command delivery indication
The security system did not
perform the command
Battery status
(follows Feedback Indication)
After the main indication it
lights up red and goes out
smoothly
Button battery needs to be
replaced. At the same time,
button commands are delivered
to the security system.

Use cases
Panic Mode
As a panic button, the Button is used to call for security company or help, as well
as for emergency notification through the app or sirens. Button support 5 types of
alarms: intrusion, fire, medical, gas leak, and panic button. You can choose the type
of alarm in the device settings. The text of alarm notifications depends on the
selected type, as well as the event codes transmitted to the central monitoring
station of the security company (CMS).
Consider, that in this mode, pressing the Button will raise an alarm regardless of
security mode of the system.
An alarm if Button is pressed can also in the Ajax security system.
Button can be installed on a flat surface or carried around. To install on a flat
surface (for example, under the table), secure the Button with double-sided
run a scenario

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
