AJAX Button User Manual

adhesive tape. To carry the Button on the strap: attach the strap to the Button using
the mounting hole in the main body of the Button.
Control Mode
In the Control mode, the Button has two pressing options: short and long (the
button is pressed for more than 3 seconds). These pressings can trigger the
execution of an action by one or more automation devices: Relay, WallSwitch, or
Socket.
To bind an automation device action to a long or short press of a Button:
1. Open the and go to the Devices tab.Ajax app
2. Select Button in the list of devices and go to settings by clicking the gear icon
.
3. Select the Control mode in the Button mode section.

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
