AJAX Button User Manual

Please note that Holder is sold separately.
How to carry around Button
The button is convenient to carry with you thanks to a special hole on its body. It
can be worn on the wrist or around the neck, or hung on a key ring.
Button has an IP55 protection rating. This means that the device body is protected
from dust and splashes. Tight buttons are recessed into the body and software
protection helps to avoid accidental pressing.
Maintenance
When cleaning the key fob body, use cleaners that are suitable for technical
maintenance.
Never use substances containing alcohol, acetone, gasoline and other active
solvents to clean the Button.
2. Press the button to test whether the commands can reach the hub. If not,
choose another location or use a .
When connecting Button via ReX, keep in mind that the button does not automatically
switch between range extender and hub. You can assign Button to a hub or another
ReX in the Ajax app.
ReX radio signal range extender
3. Fix Holder on the surface using the bundled screws or double-sided adhesive
tape.
4. Put Button into the holder.
Buy Holder

AJAX Button Specifications

General

Type	Wireless panic button
Communication Protocol	Jeweller
Power Supply	CR2032 battery
Battery Life	Up to 5 years
Weight	16 g
Water Resistance	IP54
Number of Buttons	1
Accidental Click Protection	Yes
Transmitter Power	Up to 20 mW
Modulation	GFSK
Operating Humidity	Up to 75%
Ingress Protection	IP54
Communication Range	Up to 1300 meters in open space
Operating Temperature Range	From -10°C to +40°C
Compatibility	Ajax hubs
Alarm Type	Panic
Communication Range with Central Unit	Up to 1300 m in an open space
Operating Frequency	868.0–868.6 MHz or 868.7 – 869.2 MHz, depending on the region
