AJAX DoorProtect User Manual

Detector connecting to the
, and
Lights up for a few seconds
Alarm / tamper activation
Lights up green for about one
second
Alarm is sent once in 5
seconds
Battery needs replacing
During the alarm, it slowly
lights up green and slowly
goes out
Replacement of the detector
battery is described in the
manual
Functionality Testing
The Ajax security system allows conducting tests for checking the functionality
of connected devices.
The tests do not start immediately but within 36 seconds by default. The
starting time depends on the ping interval (the paragraph on “Jeweller” settings
in hub settings).
Installing the Detector
Selecting the location
Location of DoorProtect is determined by its remoteness from the hub and
presence of any obstacles between the devices hindering the radio signal
transmission: walls, inserted oors, large objects located within the room.
The device developed only for indoor use.
hub ocBridge Plus
uartBridge
Battery Replacement
Jeweller Signal Strength Test
Detection Zone Test
Attenuation Test

AJAX DoorProtect Specifications

General

Battery life	Up to 7 years
Tamper alarm	Yes
Operating humidity	Up to 75%
Protection Class	IP50
Type	Wireless
Detection distance	1 cm
Communication range	Up to 1, 200 m in an open space
Battery type	CR123A battery
Operating temperature range	-10°C to +40°C
Dimensions	20 x 90 mm
Radio frequency	868.0 - 868.6 MHz
Compatibility	Hub
