AJAX Relay User Manual

For detection and pairing to occur, the device should be located in the coverage
area of the hub’s wireless network (at the same object). The connection request
is transmitted only at the moment of switching on the device.
If the device failed to pair, wait 30 seconds and then retry. Relay will appear in
the list of hub devices.
The device statuses update depends on the ping interval set in the hub settings.
The default value is 36 seconds.
When switching on for the first time, Relay contacts are open! When deleting Relay from
the system, contacts open!
States
Parameter Value
Jeweller Signal Strength Signal strength between the hub and Relay
Connection
Connection status between the hub and the
relay
Routed Through ReX
Displays the status of using the ReX range
extender
Active State of the relay contacts (closed / open)
Voltage The current input voltage
Temporary deactivation
Displays the status of the device: active or
completely disabled by the user
Firmware Device firmware version
Device ID Device identifier
3. Click Add — the countdown will begin.
4. Press the functional button.
1. Devices
2. Relay

AJAX Relay Specifications

General

Actuating element	Electromagnetic relay
The service life of the relay	200, 000 switchings
Operating modes	Pulse and bistable
Pulse duration	0.5 to 255 seconds
Parameter control	Yes (voltage)
Supply voltage range	7 – 24 V (DC only)
Voltage protection	Yes, min — 6.5 V, max — 36.5 V
Maximum load current*	5 A at 36 V DC, 13 A at 230 V AC
Maximum current protection	No
Device energy consumption	Less than 1 W⋅h
Frequency band	868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
Effective radiated power	3.99 mW (6.01 dBm), limit — 25 mW
Modulation of the radio signal	GFSK
Maximum distance between the device and the Hub	Up to 1000 m (any obstacles absent)
Communication ping with the receiver	12 – 300 sec (36 sec default)
Compatibility	Operates only with all Ajax hubs, and range extenders
Shell protection rating	IP20
Operating temperature range	From 0°С to +64°С (ambient)
Max. temperature protection	Yes, over 65°C at the place of installation or over 85°C inside the Relay
Operating humidity	Up to 75%

Weight and Dimensions

Dimensions	39 × 33 × 18 mm
Weight	25 g
