10
Installation (Cont.)
Outdoor Unit
Size of Shape (mm)
A (mm) B (mm)
720x260x540 540 271
802x298x535 546 316
After Sales Support
1300 886 649 | info@tempo.org
Installing the Outdoor Unit
• The outdoor unit must be firmly fixed so it does not fall over in strong wind.
• Install the unit on a cement base, as illustrated below.
• If the unit is to be installed in areas with strong wind, such as in coastal
areas or at places high above sea level, the outdoor unit should be installed
against a wall to ensure normal fan operation, and the blocking plate should
be used.
• Make sure the mounting surface is made of solid materials and is strong
enough to support the unit in operation. Otherwise, measures such as
reinforcement, support or vibration damping should be adopted.
