Installation (Cont.)
After Sales Support
1300 886 649 | info@tempo.org
Shape and form of the pipe
• Wrap up all pipe, water discharge and connection wire from top to below.
• Cover the connections and fix them with two plastic rings.
• Wrap up the pipes with tape alongside the wall and fix them to the wall with
clips. These steps are usually adopted when the outdoor unit is installed
below the indoor unit.
• In case that you want to have an
additional water discharge pipe, the
end of the pipe should be within a
certain distance towards the surface
(don’t let it drop under water, fix it onto
the wall so it won’t be swayed by wind).
• Wrap the pipes and connection wire
well from bottom to top.
• To prevent water entering the room,
wrap up the pipes that are rounded up
by the wall corners, as illustrated.
• Use clips or other fixture to fasten the pipes to the walls.
