24
SYSEX TX - Page 7
SYSEX TX allows you to transfer Preset data from the
MPD24, including Controller Numbers, MIDI Channels and
various other parameters via SysEx.
1. While in GLOBAL MODE, use [ > ] button to scroll to
SysEx Tx.
2. Use the [VALUE] dial to select which preset’s
information you would like to transfer.
3. Press [ENTER] to transfer the preset data via SysEx to
the MIDI/USB port.
SysEx transfers to the MPD24
You can also load preset data into the MPD24 from an external source
by “playing” a SysEx file into the MPD24. This can be done with a
variety of SysEx applications, many of which are widely and freely
available over the Internet.
1. Make sure that the device is connected to the MPD24 either via
the USB or the MIDI IN port.
2. Make sure that you are in Preset Mode.
3. “Play” the SysEx file on your external device or computer.
Please note that when transferring SysEx information into the MPD24,
the data will override the data of the original Preset which was sent to
your SysEx editor. For example, if you transfer Preset 5 to your SysEx
editor and then send it back to the MPD24, the data will overwrite
Preset 5.
VERSION - Page 8
VERSION allows you to see what version of the operating
system and firmware is currently loaded onto the MPD24.
While in GLOBAL MODE, use [ > ] button to scroll to Ver for
version information.
