27
SPECIFICATIONS
GENERAL
Display custom LCD w/ backlight
Dimensions (WxDxH) 318mm x 283mm x 50mm (68mm MAX)
Weight 2.18 kg
Power
~200mA, 5V DC via USB
~500mA, 6V DC via external adaptor (MP6-1)
Number of Presets 30
MIDI output channels over USB 48 (16 channels x 3 ports)
MIDI output channels from 5-pin MIDI 16
Drum pads 16 (velocity and pressure sensitive)
Drum pad banks 4
Sliders 6
360 degree knobs 8
Accessories
• User’s manual
• USB cable (1m)
• CD-ROM disc with Uniquest Editor and
other extras
• DVD-ROM disc with BFD Lite
INPUTS/OUTPUTS
MIDI inputs 5-pin DIN x 1
MIDI outputs 5-pin DIN x 1
USB Slave connector x 1 (MIDI over USB)
DC IN 6V DC, 500mA
