Akai MPK225

3
ICSTM32F100C4T6 IC STM32F100C4T6B LQFP-48 1 (U7)
2
ICYH103M04 IC(STM32F103VCT6+Program)LQFP-100 1 U12
3
ICSTM32F103VCT6 IC STM32F103VCT6 LQFP-100 1 (U12)
2
JKDJ-0702B-020 DC Base 2.0MM 1 J7
2
PC13A009 Main PCB 4Layer FR-4 140*75MM 1 -
2
PT1304702 PLATE 1 (J5)
2
RS000010J03 RES 0Ω 5% SMD 0603 20 R2~5,13,26,32~35,62,73,79,80,85,94,97
R98,100,105
2
RS000110J03 RES 1Ω 5% SMD 0603 1 R99
2
RS001K10F03 RES 1K 1% SMD 0603 8 R15,28~30,38,39,69,71
2
RS002210F03 RES 22Ω 1% SMD 0603 2 R45,46
2
RS004710F03 RES 47Ω 1% SMD 0603 2 R20,67
2
RS010010F03 RES 100Ω 1% SMD 0603 9 R50~52,57,65,68,102,113,129
2
RS010K10F03 RES 10K 1% SMD 0603 28 R1,6,8,10,11,14,19,22,27,42~44,90,101
R112,115,116,138,140~142,500~503
R505~507
2 RS011K10F03 RES 11K 1% SMD 0603 2 R82,86
2 RS012K10F03 RES 12K 1% SMD 0603 1 R9
2 RS01K110F03 RES 1.1K 1% SMD 0603 1 R137
2 RS01K510F03 RES 1.5K 1% SMD 0603 1 R21
2 RS022010F03 RES 220Ω 1% SMD 0603 3 R16~18
2 RS027010F03 RES 270Ω 1% SMD 0603 1 R66
2 RS047510F03 RES 475Ω 1% SMD 0603 1 R136
2 RS080610F03 RES 806Ω 1% SMD 0603 2 R74,135
2 RS100K10F03 RES 100K 1% SMD 0603 3 R37,40,110
2 RS11K810F03 RES 11.8K 1% SMD 0603 1 R63
2 RS15K810F03 RES 15.8K 1% SMD 0603 4 R60,61,75,83
2 RS1K3310F03 RES 1.33K 1% SMD 0603 1 R53
2 RS220K10F03 RES 220K 1% SMD 0603 3 R72,87,106
2 RS22K110F03 RES 22.1K 1% SMD 0603 1 R64
2 RS2K1510F03 RES 2.15K 1% SMD 0603 1 R70
2 RS2K3210F03 RES 2.32K 1% SMD 0603 1 R56
2 RS33K210F03 RES 33.2K 1% SMD 0603 1 R58
2 RS3K3210F03 RES 3.32K 1% SMD 0603 4 R76,77,95,96
2 RS42K210F03 RES 42.2K 1% SMD 0603 2 R81,84
2 RS470K10F03 RES 470K 1% SMD 0603 1 R48
2 RS47K510F03 RES 47.5K 1% SMD 0603 1 R59
2 RS4K7510F03 RES 4.75K 1% SMD 0603 2 R54,55
2 RS820K10F03 RES 820K 1% SMD 0603 1 R31
2 RS82K510F03 RES 82.5K 1% SMD 0603 1 R78
2 RS8K0610F03 RES 8.06K 1% SMD 0603 1 R41
2 TE852542001 Connector 2 J500,501
2 UH201209T-601Y BEAD 600Ω @100MHz 2A ±25% 0805 1 L3
2 UHLPF3218MF100M 10UH 1A 0.29Ω SMD 2 L1,2
2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1 X1
1 TWPC13A01301 FSR PCB Assembly 1 32
2 AL2-49-0070 Diode BAV70 4 D17~20
2 AL2-71-1324 IC LMV324 SOP-14 1 U41
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 4 C82,84,86,88
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C4,12,13,80
2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 3 C2,11,14
2 CS561J5003NPO CCAP SMD 560pF/50V 5% 0603 NPO 4 C81,83,85,87
2 FCN1T1001402 FCN DOWN Touch ZIF SMD Pitch=1.0mm 14P 1 J1
2 IC74HC595 Integrated Circuit 3 U18,24,37
2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 8 LED100~107
0603 angle 120°
