Akai MPK225

2 PC13A013 FSR PCB 2-Layer FR-4 150*81MM 1 -
2 RS004710F03 RES 47Ω 1% SMD 0603 2 R160,186
2 RS010K10F03 RES 10K 1% SMD 0603 4 R220,224,228,232
2 RS012K10F03 RES 12K 1% SMD 0603 4 R218,222,226,230
2 RS022110F03 RES 221Ω 1% SMD 0603 16 R146,147,149,150,152,153,155,156,158,185
R188,189,191,192,194,195
2 RS043210F03 RES 432Ω 1% SMD 0603 8 R145,148,151,154,157,187,190,193
2 RS047010F03 RES 470Ω 1% SMD 0603 4 R219,223,227,231
2 RS04K710F03 RES 4.7K 1% SMD 0603 4 R221,225,229,233
1 TWPC13A01401 Top Right Front PCB Assembly 1 33
2 PC13A014 Top Right Front 2Layer FR-4 307*123MM 1
2 TWPC13A014A01 TOP Right Front PCB Assembly 1
3 AA822524X IC SN74HC165PW 4 U1,2,3,4
3 AA822748X Diode BAV99 1 D3
3 AL0-09-0044 Variable Resistor 8 R8,9,12,22,32,44,65,91
3 AL0-17-0470 RES Array 4X47 1/10W 0603 6 R204~209
3 AL0-17-8103 RES ARRAY 8X10K 4 R3,4,35,64
3 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 2 Q11,14
MMBT4401LT1 NPN SOT-23)
3 AL2-51-4403 Transistor 2N4403 PNP SOT-23 4 Q1,10,12,13
3 AL2-62-0004 IC 74AHC04 1 U22
3 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 16P Soic 2 U9,10
3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 3 C63,65,91
3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C89,92,94
3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 36 C5,7,8,15~18,21,23~41,43~45,66,67,69
C90,93,95
3 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 10 C1,3,6,19,20,75~79
3 DIZDSMAJ10ASM Diode 11.5V 400W 23A 1 D21
3 ECS22616B Capacitor Electrolytic 22uF/16V B type SMD 1 C22
3 FCN1T1001402 FCN DOWN Touch ZIF SMD Pitch=1.0mm 14P 1 J3
3 FCN1T1001602 FCN Down Touch ZIF SMD Pitch=1.0mm 16P 1 J2
3 FCN1T1002602 FCN Down Touch ZIF SMD Pitch=1.0mm 26P 1 J18
3 FCN1T1003001 FCN Down Touch ZIF SMD Pitch=1.0mm 30P 1 J17
3 IC74HC595 Integrated Circuit 3 U62~64
3 LDKPT-1608CGCK Liquid-emitting Diode Green SMD 0603 1 LED22
angle 120°
3 LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 1 LED21
angle 120°
3 LDKPT-1608SYCK Liquid-emitting Diode Yellow SMD 0603 15 LED1~8,14~20
angle 120°
3 RS000010J03 RES 0Ω 5% SMD 0603 5 R11,13,94,247,248
3 RS001510F03 RES 15Ω 1% SMD 0603 1 R235
3 RS004710F03 RES 47Ω 1% SMD 0603 7 R1,5,7,76,77,451,452
3 RS010K10F03 RES 10K 1% SMD 0603 8 R10,234,237~240,244,246
3 RS047010F03 RES 470Ω 1% SMD 0603 1 R236
3 RS068010F03 RES 680Ω 1% SMD 0603 1 R241
3 RS4K7510F03 RES 4.75K 1% SMD 0603 1 R243
SWDC11B20214A8 Switch Rotatiomal 20 pulse 20mm push-on 1 E1
3 switch
3 SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 27 SW0~7,SW13~31
3 TE622000201 Pin Header 90° Pitch:2.00mm Single Row 1 J13
3 2P DIP
3 TE622001603 Pin Header 90° Pitch:2.0mm Single Row 1 J19
6Pin DIP
3 UHBLM18AG102SN1 BEAD 1000Ω 100MHZ 1 L7
2 TWPC13A014B01 Pitch&MOD PCB Assembly 1
