Åkerströms JUPITER 100J User Manual

Operating Manual JUPITER 100J & 150J 5 (28)
JUPITER 800/900 100J & 150J Document-ID: 948681-000
Version: A2 Author: SH
EN
START THE TRANSMITTER & ACTIVATE THE MAIN CONTACTOR
Pull out the STOP button, the transmitter makes a self-test for 0.5 seconds.
The status indicator (Batt.) starts blinking, the transmitter has been activated.
When the transmitter is activated, press button . This will actuate the
main contactors in the receiver (the main contactor of the crane closes) and
the system is now ready for operation.
NORMAL OPERATION
The transmitter is designed with two joysticks:
One for Bridge/Trolley travel and the other for Hoist motions, each direction
being divided into 2 steps (a perceptible resistance) which facilitates the run-
ning at a certain speed. The size and direction of the joysticks movements are
equal to the speed and direction of the objects motions. Bridge and Trolley
can be run simultaneously with the same joystick. The motion stop when the
joystick is brought to neutral, if not depress the safety STOP button.
STOP
Depress the safety STOP button for stop.
SLOW SPEED (MICRO) OPERATION
Set the selector switch for Slow/ Normal/ Extra in position
Slow. The objects motion will now only operate at a factory pre-set slow
speed regardless of the movements of the joystick. The joystick movements
are also interlocked during this time so that only one movement can be oper-
ated at a time.

Åkerströms JUPITER 100J Specifications

General

Brand	Åkerströms
Model	JUPITER 100J
Category	Remote Control
Language	English
