Åkerströms SESAM 800 Manual

OPERATING MANUAL 14 (112)
Document-ID: 947422-000 Multi Version: C0
EN
13 OUTPUT CONFIGURATION
Each of the 6 outputs in the receiver can be congured as either momentary or remaining
(latched) using a special conguration mode.
Note! The transmitter/s and receiver must be paired before output conguration can be done,
see chapter 12.
Caution. All outputs must be disabled before conguration by disconnecting the
Output Power Input (SW) terminal (see g. 3).
13.1 To congure the receiver outputs do the following:
1. Powero󰀨thereceiver(ifyouhaveaconversionboxfor230VACwait10
seconds).
2. DisconnecttheOutputPowerInputterminal,seegure3.
3. PlacethejumperintheJ1(left)position (forpositionsee
8
in Figure 1).
4. Pressandholdthe“Learn/Erase”button(seeg.1)whilepoweringonthe
receiver.
(IfJumperJ1isinleftpositionatpowerupandthe“Learn/Erase”buttonis
not pressed the receiver will stop and indicate error 4. Restart the receiver
whilepressingthe“Learn/Erase”button.)
5. ContinuetopressthebuttonuntilallOutputsLEDsarelit(see
10
ing.1).
6. Releasethebutton.TheOutputLEDswillnowdisplaythecurrenttoggle
conguration.LED7(see
7
ing.1)willindicaterelaycongurationmode
withaslowblink(1Hz).
7. Usebutton1...6onthetransmittertoconguretheoutputsasmomentaryor
remaining (latched). Output LED lit indicates remaining mode active.
8. Tostorethecongurationpressthelearnbuttonfor1second.Successful
storeisindicatedwith3ashesonLED7.
9. Powero󰀨thereceiver(ifyouhaveaconversionboxfor230VACwait10
seconds).
10. ReinstalltheJumperinitsprevioussetting.
11. Start the receiver.
