AKO PROPlus 3PH BASIC - Page 25

1569H042 Ed.03
* See table page 26.
**The options available in each setting can vary depending on the model.
Level 1.- ALARM CONTROL
Level 1.- GENERAL STATUS
25
Description
Units
Min
Def
Max.
A0
Configuration of temperature alarms (Page 18): 0=Relative to SP 1=Absolute
0
1
1
A1
Maximum alarm probe 1 (must be greater than SP) (Page 18)
(ºC/ºF)
A2
99,0
99,0
A2
Minimum alarm probe 1 (must be greater than SP) (Page 18)
(min.)
-45
-45
A1
A3
Temperature alarm delay during start-up (Page 19)
(min.)
0
0
120
A4
Temperature alarm delay after completion of a defrost (Page 19)
(min.)
0
0
99
A5
Temperature alarm delay after reaching the value of A1 or A2 (Page 19)
(min.)
0
30
99
A6
External alarm delay when receiving digital input signal (P10 or P11=2 or 3) (Page 19)
(min.)
0
0
120
A7
Deactivation delay of the external alarm when the signal of the digital input disappears
(P10 or P11=2 or 3) (Page 19)
(min.)
0
0
120
A8
Show warning if defrost is terminated by time-out 0=No, 1=Yes (Page 18)
0
0
1
A9
Alarm relay polarity 0= Relay ON in alarm (OFF no alarm);
(Page 19) 1= Relay OFF on alarm (ON with no alarm)
0
0
1
A10
Temperature Alarm Differential (A1 and A2) (Page 18)
(ºC/ºF)
0,1
1,0
20,0
A12
Door open alarm delay (if P10 or P11=1) (Page 19)
(min.)
0
10
120
EP
Exit Level 1
Level 2
Description
Units
Min
Def
Max.
P1
Delay of all functions on receiving electrical power
(min.)
0
0
255
P2
Función del código de acceso (password)
0= Inactivo; 1= Bloqueo acceso a parámetros; 2= Bloqueo del teclado
0
0
2
P3
Configures the default factory settings
0= No changes 1=Return to default settings
0
0
1
P4
Selection of type of inputs 1=1 probe 2=2 probes
1
2
2
P5
MODBUS address (Page 21)
1
1
225
P6
AUX 1 relay configuration** 0=Deactivated
1=Pump down 2= Same compressor status
0
*
2
P62
AUX 2 relay configuration** 0=Deactivated 1=Alarm
2= Same compressor status 3=Same unit status 4=Pump down
0
*
4
P63
AUX 3 relay configuration** 0=Deactivated 1=Light
2=Same unit status
0
1
2
P7
Temperature display mode
0=Integers in ºC 1=One decimal in ºC
2=Integers in ºF 3=One decimal in ºF
0
1
3
P8
Probe to be displayed (as per parameter P4)
0=visualization of all the probes in sequence; 1=Probe 1 2=Probe 2
0
1
2
Level 2
