6.4 60320010 3356 TRIDENT SINGLE GALLONAGE W/HARNES ID (OTC SPECIAL)
CONNECTOR – J1
Pin Function Configuration
1 Vehicle Battery + Vehicle Battery +
2 Vehicle Battery - Chassis/Ground/Negative
3 Aux. Battery + (Optional) Positive
4 Aux. Battery - (Optional) Negative
5 H-Bridge – Axis 5 (On) Discharge moves on when pin 5 positive with respect to pin 6
6 (Off) Discharge moves off when pin 6 positive with respect to pin 5
7 Output #1 Discharge Out (Sourcing Out, 2 Amps Max.)
8 Output #2 Unused (Sourcing Out, 2 Amps Max.)
9 Output #3 Unused (Sourcing Out, 2 Amps Max.)
10 Bistable Relay Contact
Output (Form C)
Common
11 N.O. Contact (1 Amp Max.) Connected to pin 10 when Parked (Stowed)
12 N.C. Contact (1 Amp Max.) Connected to pin 10 when Unparked (Deployed)
13 Switch Input #1 (Enable) Connect to +Bat. Or –Bat. Disconnect to Disable
14 Switch Input #2 (Master Right/L¯e¯f¯t¯ ) Connect to +Bat for Right, to –Bat for Left (Rotation)
15 Switch Input #3 (Master Up/D¯o¯w¯n¯ ) Connect to +Bat for Up, to –Bat for Down (Elevation)
16 Switch Input #4 (Master Stream/F¯o¯g¯ ) Connect to +Bat for Stream, to –Bat for Fog (Pattern)
17 Switch Input #5 (Discharge On/O¯f¯f¯ ) Connect to +Bat for On, to –Bat, or N.C. for Off
18 Switch Input #6 (Lights) Connect to +Bat to Energize, Disconnect for Off
19 Switch Input #7 (Osc. Set/P¯a¯u¯s¯e¯ ) Connect to +Bat for Set, to –Bat for Pause (Oscillation)
20 Switch Input #8 (Harness ID2) Customer Proprietary
21 Switch Input #9 (Harness ID1) Customer Proprietary
22 Aux. Power Out (Communications Power) (Aux. Power – 1 Amp)
23 CAN HI Vehicle CAN – J1939 (optional)
24 CAN LO Vehicle CAN – J1939 (optional)
25 Common (Communications Power) (Common – Ground)
26 CAN HI (Unused)
27 CAN LO (Unused)
28 DATA + DATA B(+) RS-485 (Optional)
29 DATA - DATA A(-) RS-485 (Optional)
NOTE: It is always best to consult the control drawing D-1032-505 for up to date details.
48
