Akuvox R27 series Quick Guide

Installa
1.1With 86x86 mm embedded juncon box in the wall
St
ep 1: Wall-mounng Box or Flush-mounng kits Installaon
1.Wall Moun
2
Installaon Environment
Indoor and outdoor installation are supported.
If installing the device outdoors, please don't place device under direct sunlight, it will bring a bad effect or be broken with
the high temperature.
If installing the device indoors, please keep device at least 2 meters away from light, and at least 3 meters away from
window and door .
Backlight Direct sun
through window
Close to lightDirect sunlight Indirect sunlight
through window
Fix the wall-mounting box with four
ST4x20 screws and two M4x30 screws.
1.2 Without embedded juncon box in the wall
Fix the wall-mounting box on to the
embedded box (86) with two M4x30
screws, mark the positions of the four
holes of the wall-mounting box at the
hole center.
Take off the box and drill the four marked
holes with a depth of 25 mm using 5 mm
drill bit hand drill before inserting the plastic
wall anchors into the drilled holes.
