ASM
USER’S MANUEL
PAGE: 26
03.04-B1
9.10. THE LOW ROLL MATERIAL COMPESSION (UP –DOWN
MOVING)
1- Bring the lower top rolls up,turning the arm 01-number.
2- After the sheet metal tightening between the lower and upper top rolls,
take the bending sheet out,the lower sheet metal must bring down.Of this do the same operation
opposite.
01
9.11. TAKEN THE BENDING MATERIAL OUT OF THE MACHINE
After the bending operation of the material ,bring the lower rolls down and;
1- Take out the upper roll eccentric . So the upper top rolls bearing will come off position.
2- Pull the upper top rolls shaft sttraight yourself.Take out the shaft from the housing.
3- Take out the bending material from the opening space.
