12 Technical specifications
TECHNICAL SPECIFICATIONS
GENERAL
Number of channels 8
Channel spacing 12.5 KHz
Frequencies CH1:446.00625 MHz
CH2:446.01875 Mhz
CH3:446.03125 Mhz
CH4:446.04375 Mhz
CH5:446.05625 Mhz
CH6:446.06875 Mhz
CH7:446.08125 Mhz
CH8:446.09375 Mhz
Batteries 3 AA type alkaline 1.5V or 1.2V Ni-Cd/NiMH
Temperature -20°C to +55°C
Frequency control PLL synthesiser
Frequency stability ± 2.5 PPM
Weight 105 gr. (without batteries)
Dimensions 50 x 95 x 25 mm
RECEIVER
Sensitivity 12dB SINAD better than 0.35µV
Squelch automatic
Audio output power 0.3Watts (max)
Frequency response 300 - 3000 Hz
