Controls description
Top
1. “ON-OFF/VOLUME“ dial. With this control you can turn
on or off the radio and adjust the volume to a comfortable
level. In OFF position the transceiver is switched off.
2. “SPK MIC.” (Speaker/microphone standard connector).
Connect this jack to a speaker/microphone or a throat
activated mic. (optional accessories).
3. Antenna
Front
4 Controls description
OFF/VOL
1
2
3
MIC
BSCAN DW VOX SAVE
BEEP
9
10
6
7
8
5
4
English
