Page #6 background imageLoading...
Page #6 background image
ADC-ACC1-17 Installation Guide | 5
RUNNING
Status LEDS
 All LEDs OFF
 LEDs 1, 2, 3, 4, 5, 6, and 7 are sequenced
during initialization. LEDs 1, 3, and 4 are turned ON for
approximately 1.5 seconds after the hardware initialization
has completed, then the application code is initialized. The
amount of time the application takes to initialize depends
on the size of the database, about 3 seconds without a
card database. Each set of 10,000 cards will add about 3
seconds to the application initialization. When LEDs 1, 2,


this state.
If the sequence stops or repeats, perform the Bulk Erase

If clearing the memory does not correct the initialization
problem, contact technical support.
LED Description
Connecting to Alarm.com =
Connected to Alarm.com =
Alarm.com Communication Activity
Readers (combined):
Clock/Data or D1/D0 Mode = Flashes when Data is
Received, Either Input.
RS-485 Mode = Flashes when Transmitting Data
Input IN1 Status:
OFF = Inactive,
ON = Active, Flash = Trouble See Note 1
Input IN2 Status:
OFF = Inactive,
ON = Active, Flash = Trouble See Note 1
Cabinet Tamper
Reserved
