In the box
Recommended tools
Thermostat overview
Buttons
UP: Adjust target temperature up.
MODE: Change thermostat between
HEAT, COOL, AUTO, EMER
and OFF modes.
DOWN: Adjust target temperature.
Also include and exclude from
the network.
Modes
HEAT: Will activate the heating system.
COOL: Will activate the air conditioner.
AUTO: Will select either the HEAT
or COOL mode automatically.
EMER: For use with heat pumps only.
Will bypass the heat pump and
enable auxiliary/emergency heat.
OFF: The system will not heat or cool.
Display
HEAT: Illuminated in HEAT, EMER
or AUTO mode.
COOL: Illuminated in COOL
or AUTO mode.
RADIO: Illuminated during the
wireless configuration.
❶ Display
❷ Heat
❸ Cool
❹ Radio
❺ Up
❻ Mode
❼ Down
Phillips screwdriver PencilPower drill (⁄” drill bit) Needle-nose pliers
Thermostat Back plate Trim plate
Drywall screws (3) Drywall anchors (3) AA batteries (4)
❶
❷
❸
❹
❺
❼
❻
