12 13
Configure the system
The thermostat configuration will be done on
your online account. Here you can configure the
parameters of the system, such as: Heat Pump
or Normal, number of heat and cool stages,
heating fuel, calibration temperature, and
configurable terminal (Z). In your online
account, you will have to enter the thermostat
configuration. Refer to page 7 for the
appropriate diagrams when you set up
the thermostat.
While the default settings online will be
sufficient in most cases, you also have the
option to change advanced configuration
settings, such as: Swing, Differential, Recovery
Setting, Fan Circulation Period, Fan Circulation
Duty Cycle, Maximum Setpoints, Minimum
Setpoints, and Thermostat Lock.
CAUTION: Be careful when changing advanced
configuration settings. These configuration
settings should only be changed by those
familiar with heating and cooling systems’
parameters. Contact a local HVAC
professional for help.
Manual configuration of HVAC system
on thermostat
The system type listed in the table below
can be physically set on the thermostat by
doing the following:
❶ Put the thermostat in OFF mode.
❷ Press and hold the UP button for
5 seconds until the display shows
a version number.
❸ Press and hold the UP button again
for 5 seconds until the display shows
your HVAC setup.
❹ Press the UP/DOWN buttons
to select the thermostat configuration
from the table below.
❺ Press the MODE button to confirm
your selection.
Configuration System Type Description/Note
NORM
Normal 2-heat 2-cool system
Normal electric heating system, thermostat
turns on fan with heat. Two or fewer stages
of heating and of cooling are allowed.
FOSL
Fossil 2-heat 2-cool system
(for hydronic heat w/no fan)
Normal fossil heating system, thermostat
does not turn on the fan using the G wire when
heating. Gas furnace or hydronic usually.
PUMP
Heat pump (O terminal)
Heat pump using O in the O/B termina with
two or fewer stages of electric aux heating.
PMPS
Heat pump (B terminal)
Heat pump using B in the O/B termina with
two or fewer stages of electric aux heating.
DUAL
Dual fuel system (O terminal)
Heat pump with two or fewer stages of fossil
aux heating using O in the O/B terminal.
DULB
Dual fuel system (B terminal)
Heat pump with two or fewer stages of fossil
aux heating using B in the O/B terminal.
