Alba 22/207F - TV Input;Output Ports

Connections
Bringing it all together
Connections22
If you require any technical guidance or find that your TV is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,
EARPHONE Earphone socket
Video Video input
L/R L/R audio input
COMPONENT (HD) Component input (YPbPr)
HDMI 1 HDMI input
HDMI 2 (ARC) HDMI input
SCART SCART input
RF IN RF / TV aerial input
COAX audio out Digital audio output
USB USB input
CI CARD IN Common Interface module
1
2
3
4
5
6
7
8
9
10
11
*The Ethernet port is used only for Freeview HD services only.
Connections
EARPHONE
VIDEO
R
L
Y
Pb
Pr
US B
CI CARD IN
COAX
1
9
2
10
11
3
45
78
6
