Mainboard PM73V
3
Onboard IDE Connector:
One IDE connector that support up to two IDE devices
Supports Ultra ATA 100/ 66/ 33
Supports high capacity hard disk drives
Serial ATA II Connector:
Four SATA II connectors that support up to four SATA II HDDs
Supports SATA 2.0 specification which provides 3 Gb/s transmit rates
Supports RAID 0/ 1 mode
I/O facility Connectors:
Supports one PS/2 mouse port and one PS/2 keyboard port
Supports one VGA (=D-sub) port
Supports one serial port（COM1）header, one HDMI-SPDIF OUT (JP4) header and
one IrDA（IR）header with external devices connected
Universal Serial Bus:
Four onboard USB 2.0/ 1.1 ports
Two front USB headers come with this mainboard supporting four additional USB
ports to be set
Supports a maximum of eight USB 2.0/ 1.1 ports for compliant devices
Onboard HD Audio CODEC (ALC662):
High performance CODEC with high S/N ratio (>90 db)
Supports 6/4/2 channel playback capability
Supports jack sensing and re-tasking function
Built-in Dolby Digital Live Technology
Supports Sony/ Philips Digital Interfaces (S/PDIF) functionality (Optional)
Onboard LAN PHY:
Supports 10/100 Mbps Ethernet LAN PHY
