14
Englsih
4. Overview Radio
4.1. Controls
Nr. Beschreibung Funktion
1 Headset socket For Kenwood headsets/earphones/microphones
2 Antenna Integrated antenna for maximal performance
3 Status LED Glows green on reception and red on transmission
4 Microphone Talk into the microphone from about 5 cm away
5 Battery 2000 mAh rechargable Lithium-Ion battery
with rotating belt clip
6 On/Off/Volume Turn clockwise to increase volume
7 Speaker Audio output for incoming signals
8 Charging socket USB-C Charge via USB-C socket or the desktop charger
9 Push-to-Talk button (PTT) Press and hold to transmit
10 Channel + Short press to increase channel
11 Channel - Short press to decrease channel
12 Programable button Long press for multiple possible functions, see chapter 7
