Alcatel-Lucent 400 DECT Localisation And Notification Management

8
Configuration documentation
1
8
T Select the mode
The default mode is Enterprise.
T Select Access
There is no default value and a maximum of four digits can be keyed in. Authorised digits are 0 to
9, * and #. If there is only one access, only access 1 must be keyed in, access 2 must left empty.;
Behind Office communication solutions (office mode) only up to 3 digits are allowed.
1.6
How to program status calls
T
Access to the configuration menu
Edit notify Mode
Enterprise Office
Edit notify Access1 Access2
Enter the prefix to access the
trunk line or security
personel set in fallback mode
OR
OR
Edit notify
Enter the handset
administration code
Select one system
123
123
Password?
. . . .
123
SYSTEM 1
SYSTEM 2
Lock to any
400GEO-206

Alcatel-Lucent 400 DECT Specifications

General

Backlight color	White
Backlight display	Yes
Display resolution	98 x 66 pixels
Display number of colors	4096 colors
Type	DECT telephone
Intercom	-
Handset type	Wireless handset
Answering machine	No
Microphone frequency	1880 - 1900 Hz
Phonebook capacity	- entries
Mounting type	Desk
Product color	Black, Chrome
Number of handsets included	1
Standby time	160 h
Battery recharge time	3.5 h
Certification	ETS 300 019-1. In use Class 7.2, ETS 300 019-1-7, ETS 301 489-1
Operating temperature (T-T)	-5 - 45 °C

Weight and Dimensions

Depth	22 mm
Width	45 mm
Height	120 mm
Weight	110 g
