42 additional keys.
- Add-On Modules of types AOM10 and AOM40 can be used on the same set, but a Smart
Display Module cannot be used in conjunction with an AOM10 or AOM40.
- If an AOM10 is used with other Add-On Modules, it must be connected as the last module
on the far right of the set.
Connecting Add-On Modules
To connect an Add-On Module:
1. Remove the tab located on the right side of the set.
2. Plug the Add-On Module's RJ45 connector into the set's RJ45 connector.
3. Insert the Add-On Module attachments into the appropriate holes located on the right side
of the set.
4. Screw the Add-On Module to the set.
Note:
If the set is on when you plug in an Add-On Module, you must restart the set after connection.
Connecting headsets
The headset jack is located on the left side of the set.
The 3.5 mm female jack can receive a headset jack.
The hands-free key allows you to switch from handset, headset and hands-free.
Prerequisites
None.
Connecting a headset
To connect a headset, simply plug the headset jack into the associated connector on the side
of the set.
Connecting an external hands-free device
The external device jack is located on the left side of the set.
The 3.5 mm female jack can receive the jack of an external hands-free device.
In order to take the external hands-free device into account, the set's customization for the jack
must be set to “Handsfree”.
Prerequisites
None.
Connecting an external hands-free device
To connect an external hands-free device, plug the external device's jack into the associated
connector on the side of the set.
Programming keys
This section describes how to program a programmable key from the:
Chapter
4
&'(
4-74
